Alpha 500k Split Shaft Potentiometer
Pickup available at Northwest Guitars
Usually ready in 1 hour
Genuine full size Alpha Pots
Genuine, full size, ALPHA POTS Log A or Linear B Potentiometers. These Pots are fitted as standard on Mexican/Squier Stratocaster models, as well as most Epiphone guitars.
With a Split Shaft of 5.9mm these pots are compaitble with most aftermarket plastic knobs
Cost effective replacements for noisy/scratchy Volume pots, or as an 'upgrade/replacement' for Mini Pots. High quality component with good smooth action.
Comes complete with fixing nut and plain washer.
Choose from two different shaft lenghts:
7mm - Ideal for Stratocasters
11mm - Ideal for Epiphone and other guitars where the electrics are mounted though the body, rather than top mounted
Product Details
- 10% tolerance for greater contsistancy & accuracy.
- Very robust and reliable.
- Choose either Audio Taper or Linear Pot
- Total pot depth - 30mm
- Diameter of threaded shaft - 7.8mm
- Diameter of split shaft - 5.0mm
- Base of pot diameter - 23.5mm
Shipping & Returns
Order before 3pm for same day despatch Monday-Friday
Free shipping on UK orders over £199*
Click & Collect available Mon-Fri until 4pm.
See our full shipping/returns options here
Additional product information
Split Shaft Potentiometer
Full Size Pot
Value: 500K
Customer Reviews
These pots are a decent quality and work pretty well, not a perfect sweep but they don't go from 10 to zero with half a turn. I would certainly recommend them for budget projects.
Very communicative. Answered all my questions prior to me making an order. That made it very straightforward. Will definitely be buying from them again.
Speedy delivery, pot now installed and working. Great service!
I had no idea which one I needed, or the size. However, for the price I ordered 3, 2 of the smaller size and also an orange drop capacitor and fitted them into the smallish cavity of the guitar. I downloaded the correct wiring and started soldering. Surprisingly, all went well a nd now I haven a fully functioning guitar for a very cheap price. 😁👍
worked well as replacement for faulty unit - happy with purchase
